It accurately counts hard capsules, softgels, tablets, pills, candy pellets. Available for round, oval, irregular pharmaceutical solid preparations.
What bottle sizes fit the automatic bottling line?
Support plastic/glass bottles from 10ml to 500ml, including round, square, special-shaped bottles. Bottle holders can be customized according to your bottle samples.
What counting technology do you adopt?
Multi-channel optical fiber electronic counting. High precision, low error rate, no damage to tablets and capsules compared with mechanical plate counting.
What is the production speed of the full bottling line?
Small semi-auto counting machine: 10–30 bottles/min; full automatic counting bottling line with capping & labeling: 40–120 bottles/min.
Does the counting system meet pharmaceutical GMP requirements?
All contact parts are mirror polished 316L stainless steel. Fully enclosed dust-proof structure, easy disassembly for thorough cleaning, no cross-contamination between batches.
What complete stations can be matched in one bottling line?
What materials are suitable for this powder mixer?
Uniform mixing of pharmaceutical powder, granules, herbal extracts and food additives with good flowability.
How to guarantee uniform mixing without dead zones?
3D swing movement design makes materials tumble in all directions, mixing uniformity above 99%, no material deposition at corners.
What loading volume ratio is recommended?
Optimal mixing effect when filling 40%–70% of the tank volume; too full or too empty will reduce mixing consistency.
Can the mixing tank be customized with spray function?
Optional liquid spraying system for adding binders or alcohol during powder mixing process.
Is it easy to clean and sterilize the mixing barrel?
Mirror polished 316 stainless steel barrel, quick clamp structure for fast disassembly, compatible with alcohol and high-temperature disinfection.
Is there dust spillage during feeding and discharging?
Sealed feeding port with dust-proof cover, matching vacuum feeder optional for automatic feeding without dust pollution.
Q Pharmaceutical Hammer Mill / Pulverizer 药用粉碎机
A
What raw materials can the pulverizer crush?
Herb roots, herbal leaves, chemical API, excipients, grains and solid medicine blocks for pharmaceutical processing.
Can I adjust the fineness of output powder?
Different mesh screens (20–300 mesh) are interchangeable to control powder particle size as required.
Will there be cross-contamination during crushing?
Detachable stainless steel crushing chamber, fully sealed negative pressure dust collection device, no powder leakage, easy full cleaning between batches.
Is the mill suitable for heat-sensitive medicinal materials?
We offer water-cooled type hammer mill to lower working temperature and prevent active ingredients from being damaged by high heat.
What safety protection devices are equipped?
Overload protection, emergency stop button, sound insulation cover and anti-loose locking structure to ensure cleanroom safe operation.
Q Capsule Filling Machine 硬胶囊填充机
A
What capsule sizes can your filling machine support?
It can fill capsule sizes #00, #0, #1, #2, #3, #4 for empty gelatin and HPMC vegetarian capsules. Custom molds for special capsule shapes are available.
Is the machine suitable for powder, pellets and micro-granules?
Yes, adjustable filling system adapts fine pharmaceutical powder, granules and small pellets. Dosing volume can be precisely calibrated.
Does the capsule filler meet GMP clean room standards?
All material contact parts are 316L stainless steel, quick disassembly without dead angles, easy washing and disinfection. Closed feeding avoids powder flying.
How to solve capsule separation and leakage problems?
Uneven powder density, incorrect filling depth or worn sealing components are the main causes. Our machine comes with PLC weight feedback adjustment to reduce rejection rate.
Do you supply matching capsule polishing machine?
We support supporting polishing, sorting and dust removing machines to form a complete capsule filling line.
Q Wet Granulator 湿法制粒机问答
A
What pharmaceutical materials fit wet granulation?
Herbal powder, chemical raw medicine powder, excipients like starch, lactose, suitable before tableting process.
Will material stick to the granulation pot?
Our pot inner wall is mirror polished 316 stainless steel, equipped with anti-stirring adhesion scraper to reduce material waste.
Can this granulator work with fluid bed dryer as a whole line?
Perfectly matched with our fluid bed dryer, we can design full automatic granulation drying production layout for your workshop.
Is there dust overflow during granulation operation?
After each batch production, fully disassemble and clean the cutting knife, regularly lubricate the rotating bearing as our maintenance guide.
Q Rotary Tablet Press 旋转压片机问答
A
What kinds of tablets can this press produce?
Sugar tablets, medicine tablets, effervescent tablets, milk tablets, herbal tablets, round and irregular shaped tablets.
Is it easy to disassemble and clean the tablet press?
The punch, die and turret can be quickly removed without tools, no residual powder dead corners, convenient CIP cleaning.
Can the tablet hardness and weight be automatically controlled?
Equipped with PLC automatic correction system, real-time adjustment of filling depth to ensure consistent tablet weight and hardness.
What power supply do you support for overseas factories?
Customizable 220V/380V, 50Hz/60Hz to match local power in Europe, Southeast Asia, Middle East.
What’s the difference between single-punch and rotary tablet press?
Single punch for lab small batch test; rotary model for mass production with higher stability and lower noise.
Do you supply spare parts like punches and dies?
We offer matching molds and spare parts at factory cost price, fast shipping within 30 working days.
Q Blister Packing Machine 泡罩机问答
A
What materials can your blister machine process?
Our machine supports PVC, PVDC, cold-form aluminum foil, compound film, suitable for tablets, capsules, softgels. All contact parts are 316 stainless steel to meet GMP.
Can you customize blister molds for special pill sizes?
Yes. We provide free custom molds according to your product samples. Molds are polished without dead corners for easy cleaning.
What’s the daily output range of your automatic blister line?
Small lab model: 8,000–20,000 blisters/h; high-speed industrial model: 60,000–120,000 blisters/h.
Does the machine comply with CE and GMP standards for export?
All our packaging equipment passes CE certification, adopts fully enclosed dustproof structure, meets cleanroom GMP requirements for pharmaceutical factories.
How long is the machine warranty?
1 year whole machine warranty, lifetime paid maintenance and spare parts supply. We provide overseas installation training service.
